Borgeson or Firm Feel steering?

-
The cooler helps fluid temps. However, its the higher relief pressure if you're using our pumps that makes it a good choice. Not all Mopars had coolers so I wouldn't get nuts if you don't want to add it. We also smooth the fluid passages in the box for lower temps. Synthetic fluid helps as well.

I think if you have header tubes close to steering box I would add a cooler. Small blocks with cast iron manifolds cooler might not be needed.

Bob Jasinski said:
I ordered my kit from Bergman, and am not planning on installing a cooler. Please share what happened.
Click to expand...
I was doing a track day on a 9 turn 2.5 mile road course with I think 15min sessions. The fluid got hot and did not not vent enough out of the cap, built pressure and blew the top off the pump. Not the best at a hair pin turn at the end of a 1/2 mile straightaway. I changed to a type 2 style pump and added a cooler and never had the problem again. I believe Kern Dog was right behind me when that happened.

IMG_5311 (2).JPG


IMG_5312 (2).JPG

Evan? Is that you?
I remember seeing the cap and snout fly off the car! I was following you in this car:

T 6.JPG

We have a Saginaw pump reservoir that is designed for external reservoirs. It eliminates the neck and replaces it with a -10AN feed. No need to change pumps.

Cooler? You don’t need no stinking cooler! I got my set up from BAC and am pleased.

@BergmanAutoCraft what size are the lines/fittings on the pump without a reservoir? Do you have to change the fittings on the gearbox with the remote style and cooler?

Last edited:
The remote reservoir and a simple cooler is the only way to go on an open track event. I only sell PSC reservoirs as everything else I've seen is a joke.

Power Steering Reservoir.jpg

go-fish said:
Cooler? You don’t need no stinking cooler! I got my set up from BAC and am pleased.

@BergmanAutoCraft what size are the lines/fittings on the pump without a reservoir? Do you have to change the fittings on the gearbox with the remote style and cooler?
Click to expand...
Well I think I found out I did! At that time it had a Borgeson box from Pete and a stock style Saginaw pump and no cooler and synthetic fluid, clearly that had its limits and I found them. It now still has the Borgeson box but now a Turn 1 aluminum HP pump, large aluminum reservoir and an external extruded aluminum cooler and its held together for almost 9 years of abuse. I think that fixed the problem....

gold66cuda said:
Well I think I found out I did!
Click to expand...
I have a Sweet Mfg Pump on my e-body that is just like a Turn 1. I really like it as it runs the r&p AND the hydroboost. Mine is mounted on the Procharger mount plate.
Does this style pump require custom bracketry on a small block?

I am familiar with that pump, yes very similar. Sounds like its a busy pump for you and it works well?
Yes I had to fab up the bracketry for it and size a pulley for my small block application.

I received my Borgeson kit from Bergman's this week and am looking things over. In comparing the new box with the factory unit, there is a difference in the bolt hole diameters between the two. The Borgeson holes are .570" vs .490" on the Mopar box. I have the correct 12 point head 7/16" (.437") bolts, so they have a sloppy fit, and am a bit concerned about potential movement of the box. As far as a threadlocker, I won't use red, but there is a new orange out that holds better than blue, and you can still remove the bolts without heat, but takes considerable effort. I've read that early A bodies had issues with power steering boxes loosening up, and that was the basis for the invention of threadlocker.

Mopar Action magazine had a comment on this issue. Rick cut three sleeves to fit in the mounting holes in the housing of the steering unit.
He took a tubular bracket spacer or something similar to fill the void.

I bought a 3' section of of 1/2" aluminum tube at Home Depot. Drilled the center out to 7/16" and cut the spacers with a pipe cutter. Fits well now, just the right amount of play to fit it onto the K-frame. If you can find 7/16" compression ferrules they work too, but are hard to find, 3/8" and 1/2" are commonly available but won't work.


Last edited:
That is exactly what I was thinking. Some solutions are quite simple if you just think a little bit.
It is unfortunate that some stuff we buy still needs modification but hey...These are not kit-cars, these are classic cars with non original parts that are modified to work in an older car.

I didn't look for differences in bolt hole sizes. I just bolted mine in. It came loose once retightened it was fine since

Bob Jasinski said:
Coming loose is what I'm concerned about. Did you use threadlock when you first put it in? Blue?
Click to expand...
No thread lock. And I was negligent with torquing to spec too on initial install. Some blue thread lock would be a good idea.
